DA62-00914B Refrigerator Water & Ice Valve for Samsung

ER-DA62-00914b Water Valve for Samsung.

This Water Valve is for Refrigerators with Ice & Water in the door.

It has 2 Solenoid Coils, one to let the water to the icemaker the other to let water to the dispenser.

One coil has 3/16" Male Terminals & the Other Coil has 1/4" Male Terminals.

It has 2 push in outlets where the plastic tubing pushes & locks into place.

One outlet is 5/16" the other is 1/4."

Coils are rated 110-127VAC 50/60Hz. 20W.
