Product Description
TitanPro TRCF3 HVAC Round Motor Run Capacitor 3 MFD/UF 440/370 Volts
Dimensions and Specifications:
- Diameter- 1.71
- Height- 1.97
- Add 1/2 inch to height for terminal length
- Round in shape
- There are 1/4" male terminals on the capacitor
- Rated at 3 MFD/uf 440/370 Volts 50/60HZ
Features:
- Heat tolerant, tested up to 60,000 hours of run time
- Cans are made of high-grade metallized polypropylene film and proprietary Epoxidized Soybean Oil (ESO)
- Two tri-blade terminals
- Rated to 158 Degrees (Fahrenheit), Protected to 10,000 AFC
- Meets UL 810 safety standards
- NON PCB
- Long Life Operation
