Product Description
Packard part number POCFD403A
Titan HD Oval Motor Run Capacitor
Rated at 40 + 3 MFD 440/370 Volts
1.75" Depth x 2.75" Width x 3.75" Height
Made in USA
Features:
- 60,000 hours operating life
- Meets the rigorous EIA-456-A industry standard for performance and quality
- Contains metalized polypropylene film technology for self-restoration in the event of a breakdown
- Sophisticated UL-approved pressure sensitive interrupter to remove the capacitor from circuit at end of life
- Patented, environmentally-friendly oil prevents corrosion and aids in optimum heat transfer
Specifications:
- Capacitor Voltage: 440/370
- Run MFD: 40+3
- Capacitor Shape: Oval
- Brand: Titan HD
- Can / Case Size: 11
- Country of Origin: USA
- Hertz: 50/60
- Material: Aluminum Can
- Oil Type: Soybean Based
- Operating Temperature Range: -40 to 70
- Terminals: Standard blade terminals
- Tolerance: +/- 5%
- UPC: 840899110356
- Voltage: 440/370
