Product Description
Packard PDCF7.5 HVAC Dry Motor Run Capacitor 7.5 MFD/UF 440 Volts
Dimensions:
- Height- 2.2
- Length- 1.1
- Width- 1.92
- Add 1/2 inch to height for terminal length
- Rectangular in shape
- There are 1/4" male blade quick connect terminals on the capacitor
Features:
- Rated at 7.5 MFD/uf
- 440 Volts
- 50/60HZ
- Heat tolerant, capacitance tolerance of +/-5%
- Capacitors are constructed with Self-Healing Dielectric Metalized Polypropylene Film, with a Plastic ABS Case
- Two sets of terminals and a mounting bracket
- Rated to 185 Degrees (Fahrenheit), Protected to 10,000 AFC
- UL recognized, RoHS complians
