Product Description
Nidec part number EC5414E
Rescue ECM Watt Motor
Refrigeration Evaporator and Condensing Applications
Ultimate Truck Stock Motor
Specifications:
- Horsepower: 4W, 6W, 9W, 12W, 14W, 16W, 25W
- Speed: 1550/1650 RPM
- Rated Voltages: 115V-230V
- Temperature Rating: -40 C to 55 C (-40 F to 130 F)
- Amps: 0.22 to 0.75 at 115V, 0.15 to 0.45 at 230V
- Rated Hertz: 50/60 Hz
- Bearing: Ball
- Enclosure: Totally Enclosed Air Over (TEAO)
- Rotation: Reversible
Dimensions:
- Motor Diameter: 3.3 in.
- Case Length: 2.5 in.
- Shaft Height: 0.425 in.
- Shaft Diameter: 0.25 in. 20 Thread
- Weight: 2.0 lbs.
Features:
- One motor meets three standards: IP65, IP66 and IP67
- Dust, Water and Splash Resistant
- Wide range of motor strength covered (4 to 25 Watt)
- Efficiency up to 70%
- Dual Voltage: No connection change required
- Electronically Protected
- UL/CUL Approved
- Includes Plug, Speed Nut, Rubber Isolator and Spray Shield
- Universal Mounting Includes Elco Front Mounting
- Meets ATEX Directive 94/9/EC
Industry Replacement Numbers:
- EC-HE-0147, EC-HE-0170, EC-HE-0176, EC-HE-0182
- 9207F2, 9208F2, 9211, 9212, 9213
- 00621, 00624, 00650, 00654, 00655, 00651, 00656, 00657, 00852
- 05443, 05444, 05620
