Product Description
Packard PDC12.5 HVAC Dry Motor Run Capacitor 12.5 MFD/UF 370 Volts
Dimensions and Specifications:
- Height- 2.44"
- Length- 1.25"
- Width- 2.36"
- Add 1/2 inch to height for terminal length
- Rectangular in shape
- There are 1/4" male blade quick connect terminals on the capacitor
- Rated at 12.5 MFD/uf 370 Volts 50/60HZ
Features:
- Heat tolerant, capacitance tolerance of +/-5%
- Capacitors are constructed with Self-Healing Dielectric Metalized
- Polypropylene Film, with a Plastic ABS Case
- Two sets of terminals and a mounting bracket
- Rated to 185 Degrees (Fahrenheit), Protected to 10,000 AFC
- UL recognized, RoHS compliant
