Product Description
Yellow Jacket 69354 Accuprobe II HVAC Leak Detector with Heated Sensor.
Low, normal and high sensitivity levels with audible signals to quickly and easily pinpoint leaks.
Specifications:
- Heated Electromechanical Sensor (HES) Technology Detects All HFCF Refrigerants, Plus Difficult To Detect HFC Refrigerants And Blends
- Three Sensing Levels To Detect Leaks As Small As 0.06 oz./yr. Of HFCs And 0.03 oz./yr. Of HCFCs. Automatic Calibration.
- Sensitivity: HFC 0.06 oz. (1.7 g)/year; HCFC 0.03 oz. (0.9 g)/year; HFO 0.15 oz. (4.3 g)/year
- Sensor life: Over 300 hours service life with minimal cleaning and no adjustments
- Fast Response Time
- Probe length: 17
- Weight: 15 ounces
- Power: 4 AA alkaline batteries, 4.5 hours continuous life
- Made in the USA
The YELLOW JACKET ACCUPROBE II Hand-held Leak Detector detects all HCFC refrigerants such as R-22 and R-124. The ultra-sensitive long life sensor with exclusive Heated Electrochemical Sensor Technology (HES) also detects the more current, difficult-to-detect HFC refrigerants such as R-134a, R-404A, R-407C and R-410A (see page 6 for a more complete chart of detectable refrigerants). The sleek, ergonomic design of these YELLOW JACKET leak detectors makes them easy to use in close areas and extendable into hard-to-reach areas. When finding leaks, it is important to note that the AccuProbe responds to changes in concentration of refrigerant. For this reason, the detector will stop alarming even though it is held at or near the source of the leak and will not alarm again until the detector senses a change in concentration. To verify the exact location of the source of the leak, always move the probe away from the area of the leak briefly to allow the sensor to reset at a lower concentration, and then bring it back again until the exact location of the leak source has been verified. Introduction
Features:
- Microcontroller technology
- Ultra-high sensitivity to detect 0.06 oz (1.7g)/yr. of R-134a and 0.03 oz (0.9g)/yr. of R-22
- Automatic calibration and reset to ambient
- Detects HFC, HCFC and CFC refrigerants (see page 6)
- Long life stable sensor utilizing Heated Electrochemical Sensor (HES) technology
- 3 selectable sensitivity level settings
- Sleek ergonomic design
- Low battery indicator
- Temp Range 24 to 125F (-4 to + 52C)
- Humidity 0 to 95% RH noncondensing
- SAE J2791Certified
- CE Marked
- True mechanical pump
