Robertshaw 5500-202 (M) Infinite Switch Control 240 Volt for Electric Burner Units

Robertshaw Universal Infinite Burner Switch Part Number 5500-202.

It is not a Push to Turn Switch.

Switch is CW Off to High.

It is a 5 wire switch, 1/4" Male terminals labeled P, L1, L2, H1, H2. The switch is rated at 240 Volts & 15 Amps.

The switch has a "Break Off" stem that measures 1-7/8" long, It comes w/ plastic adapters that fit over the shaft & the adapters will fit the knob. The plastic adapters are 1/4", 3/16" & a figure 8.

It has 4 mounting holes in the top and also includes a mounting nut (mounting nut is rarely used), it is a universal mount.

Detailed Installation Instructions Included.
