Product Description
Full Gauge Controls MT-512E 2HP (version 13).
Digital Controller and Indicator for Heating or Cooling with Natural Defrost Through Compressor Shutdown.
It features a single relay output, for cooling or heating purposes, combined to a cyclical timer for natural defrost. The natural defrost can be forced or performed through an off refrigeration cycle. It also features a configurable digital filter, which has the aim of simulating an increase of mass in the environment sensor, thus increasing its response time, that is, the sensor response becomes slower. In addition to those features, the MT-512E 2HP has tamper-proof function that blocks the keypad preventing unauthorized users changing its settings, and a control function shutdown that deactivates the controlling outputs turning the instrument into a digital temperature indicator.
Features and Specifications:
- CE, UL and NSF certified
- Suitable for R290 and R600a gases
- Frontal IP-65 protection
- Flatec key for easy access
- Four-digit display
- Dimensions: 71 x 28 x 71 mm
- Power Supply: 115 or 230 VAC (50/60 Hz)
- Control Temperature: -58 to 221 degrees F (-50 to 105 C)
- Operating Temperature: 32 to 122 degrees F (0 to 50 C)
- Operating Humidity: 10 to 90% RH (without condensation)
- Resolution: 0.1 degrees C (-10 to 100 C) and 1 C at the rest of the range
- Max load current: 16 A (resistive-type loads) or 12 A (inductive-type loads)
- Maximum load power: 2 hp
Applications:
- Cold storages
- Reach-in coolers
- Stand-up coolers
- Stoves
- Heated floors
- Industrial heating/cooling
- Any other type of equipment requiring precise temperature control
